Do all monitor arms work with all monitors?

In general, most monitors can be mounted on a monitor arm. They typically come with a standard VESA hole pattern on the back, measuring either 75 x 75 mm or 100 x 100 mm, which allows for easy attachment to a monitor arm.

What is a VESA hole pattern?

The Video Electronics Standards Association (VESA) is the organisation that defines the standards for mounting computer monitors, TVs, and other flat panel displays using wall mounts or stands. VESA's mounting standards simplify the process for manufacturers, helping them meet consumers’ needs. This allows for affordable installation of mounts and stands, which in turn improves ergonomics and flexibility.

How can I tell if my monitor has the VESA hole pattern?

Most monitors feature a standard four-hole screw pattern located on the back. However, some monitors—especially those with built-in stands or mounts—may have these holes concealed. To access the hole pattern, you might need to remove the attached stand or rear panel, as outlined in the user manual. Additionally, you can check your monitor’s user guide, which typically includes information on VESA compatibility. Uplifting Solutions offers a wide variety of monitor arms available on our website.

How do I attach the monitor arm to the monitor?

All monitor arms are equipped with a VESA plate that features either a 100 x 100 mm or a 75 x 75 mm square hole pattern. The monitor arm attaches to the monitor using M4 screws, which have a diameter of 4 mm. Typically, these screws require a Phillips head screwdriver for installation.

What happens if my monitor has a larger hole pattern?

Larger monitors may feature hole patterns of 200 x 100 mm or 200 x 200 mm. Some even larger monitors and TVs can have hole patterns of 400 x 400 mm or 800 x 800 mm, and so on. However, it's important to note that these larger monitors are typically wall-mounted rather than desk-mounted.

If your monitor has a 200 x 200 mm screw mounting pattern, you can purchase an additional bracket to attach it to the monitor arms. The VESA bracket for 200 x 200 mm has various hole pattern combinations suitable for larger monitors.
